Medium Efficiency Bag Filter



1. Performance Characteristics of The Medium Efficiency Bag Filter



1). High ventilation, low resistance

2). Large dust capacity, long service life

3). It can effectively extend the service life of the terminal and efficient filter





2. The Structure Description of The Medium Efficiency Bag Filter



Each filter bag of the medium-efficiency bag filter is made of ultra-fine composite fibers with a special weaving method to avoid the discomfort that the old glass fiber material may cause to the human body. The filter material contains electrostatic fibers, which has a better filtering effect on sub-micron dust. Good, high dust collection rate, high air permeability, and long service life. The four sides are fused by ultrasonic, and each filter bag is fixed by a metal strip, which increases the strength and prevents the filter bag from breaking due to the frictional force of wind shear when the filter bag is at high wind speed. Each filter bag has six spacers evenly distributed in the width of the bag to prevent excessive expansion of the filter bag when it is subjected to wind pressure, increase mutual shielding, and reduce the effective filtering area and efficiency.



Filtration efficiency has a variety of specifications to choose from: F5, F6, F7, F8, F9



3. The Application of The Medium Efficiency Bag Filter



Bag filters are widely used in central air-conditioning ventilation systems, pharmaceuticals, hospitals, electronics, food and other industrial purification, and can also be used as front-end filtration of high-efficiency air filters to reduce the load of high-efficiency air filters and prolong their service life. Because the bag filter has a large windward surface, it has a large dust holding capacity and a low wind speed, and is considered to be the best medium-efficiency filter structure at present.



Purpose and usage:

1). Commercial and industrial general systems, end filtration of air conditioning systems

2). Clean room fresh air air conditioning system, last stage filtration of air supply outlet in clean room

3). Air supply main filter for FFU and other air purification equipment

4). Widely used in electronics. Optical, semiconductor, surface treatment, coating, chemical, biopharmaceutical, hospital, automotive industry and many other fields.

5). Final filtration of commercial and household air purifiers





4. The Technical Parameter of The Medium Efficiency Bag Filter



product model	Overall dimension (mm) width * height * depth	The number of bags	Rated air volume M3/H	initial resistance	rank	productiveness	material
							outline border	filter material
ZW-FD	595*595*600	5	3000	≤50Pa-≤110Pa	F5-F9	45% -99% coloratitric method	Aluminum alloy outer frame The outer frame of galvanized plate 20mm 25mm	Grade F5-f9 with melt-blown non-woven cotton
	595*595*600	6	3400
	595*595*600	8	3800
	595*495*600	6	3000
	295*595*600	3	1600
	495*495*600	5	2800



5. The Purchase Notes Aluminum Frame Efficiency Filter



▲Invoice description

The price of this shop does not include tax points, and additional tax points are required for billing. For details, please consult customer service.



▲ Shipping Instructions

The goods in this store are all large-volume goods, and the freight varies greatly in different regions. The goods do not include freight and wooden frame packaging costs. The actual freight is calculated according to the product volume, quantity, wooden frame (export wooden box) packaging, and delivery address. Before shooting, you must contact customer service to calculate the freight! In order to avoid unnecessary misunderstandings, directly photographed and not shipped, need to make up the freight and wooden packaging costs before delivery.



▲Signing instructions

In order to protect your purchase rights and provide you with high-quality services, you need to be the logistics personnel when you sign for the package. Help you to solve the problem properly and quickly (if there is no inspection and receipt, the store will not be responsible for any damage, small pieces and other reasons to return).





6. The Introduction of The Dong Guan Zhuo Wei Air Purification Technology Co., Ltd.





Wholesale high quality newest durable Medium efficiency bag filter, ​​choose China Zhuo Wei Air Purification factory, which is one of the most professional Medium efficiency bag filter manufacturers, suppliers, and manufacturers, made in China brands, our Medium efficiency bag filter durable, technical Advanced, easy-maintainable, sufficient inventory and low cost, this is the latest classic style, easy-maintainable, and we provide free samples and price lists of products, you are welcome to email us for wholesale customization of related products.



7. FAQ:



Q1: What is you minimum order quantities?

A :Our MOQ is one set which can meet your sample requirement.



Q2: What is your leading time.

A :It’s based on your quantities and the sizes of the products.Generally it takes us 20 days for one container and 10 days for sample orders.



Q3: What is your payment terms?

A :30% by T/T as deposit, balance will be payed before delivery.



Q4: Do you accept OEM&ODM?

A: Yes



Q5: Why maxi?

1). 2 years warranty time guarantee

2). 24 hours to give you prompt and further information

3). Send invitation and arrange everything for you when you come to China
